V68 Iradio
V68 iRadio is a small, light and affordable walkie talkie with practical safety and communication functions.
Functions
Built into the radio.
- 0116 Programmable Side Keys
- 02CTCSS/DCS Code
- 03High/Low Power Switching
- 04Wide/Narrow Band Switching
- 05Scanning
- 06Monitor
- 07Battery Saving
- 08Low Battery Alerts
- 09Emergency Alarm
- 10Additional Encryption
- 11TOT
Features
Long press side key 1 to activate monitor mode
Hold the toggle switch on CH- for 2 seconds to activate the emergency alarm
Hold the toggle switch on CH+ for 2 seconds to lock the keypad
Frequency hopping setup
Low battery alert
TOT
0–9 squelch level
Battery save
Technical data
Specifications
General
- Frequency Range
- 400MHz–480MHz
- Channel Storage
- 16
- Voltage
- DC 3.7V
- Antenna Impedance
- 50Ω
- Frequency Stability
- ±20ppm
- Working Temperature
- -10°C–+50°C
- Working Current
- TX: ≤1.3A | RX: ≤0.45A
- Battery Capacity
- 1100mAh
- Dimension
- 99×62×32mm (without antenna and belt clip)
- Weight
- 142g (without antenna and belt clip)
Transmitting
- TX Power
- 2W±0.3 (DC4.2V)
- Modulation Mode
- F3E
- Maximum Frequency Deviation
- ≤5KHz wide; ≤2.5KHz narrow
- Spurious Power
- ≤7.5µW
- Adjacent Frequency Power
- ≤-65dB wide; ≤-60dB narrow
Receiving
- RX Sensitivity (12dB SINAD)
- ≤0.2µV wide; ≤0.25µV narrow
- Audio Power
- ≤1W (8ohm)
- Audio Distortion
- ≤5%
- Clutter Suppression
- ≥65dB
